Pump's for vacuum or pressure from Europa family

Stand-alone CE certified and EMC compliant pump system for supplying air under pressure for aeration of SUB / SUF. Or as pressure or vacuum supply for drive of Perfusion-SUBs via control units like Clotho.

Design of Alagonia-8

One www.electroad.es model EVO10-P1 dual rubber diaphragm pump driven by a fixed RPM asynchronous motor for very long life time. For temperature control one constant operating Sunon 70 m3/hour MagLev bearing axial ventilator.

Alagonia-8 (2 x Alagonia and 1 x Sarpedon) can drive two Clio and/or Thalia SUP´s with constant max 750 ml/min liquid harvest flow and max 1/20 cleaning cycles at 1,500 ml/min flow. With either pressure or vacuum. Not both pressure and vacuum at the same time from one Alagonia!

Alagonia-8 pump cannot start-up against pressure! (no pressure pumps can!) There must be low pressure or atmospheric pressure on both sides of the cabinet one-touch fittings before start-up. If Alagonia under start-up conditions do not immediately return to normal RPM overheating and damage will occur. If Alagonia is not pressure released before start-up overheating and damage will occur.

In & Out

• Standard IEC supply socket with build-in 1 amp fuse
• 8 mm hose connection for pressure via one-touch coupling
• 8 mm hose connection for vacuum via one-touch coupling

Communication

• none

BIG

Two Alagonia pumps

BIG

Alagonia on Sarpedon reservoir

BIG

Europe tower for Lachesis

Hephaestus Stainless Steel cabinet U2 housing the Alagonia-8 pump. Further one Sarpedon reservoir below Alagonia stabilising the pressure or vacuum. At the most right a tower where blue hoses interconnect the three units. Gauges on Sarpedon help controlling pressures. The brass pressure regulator visible at lower right corner on Sarpedon regulate for constant 1 bar pressure.

Typical life time for the diaphragm pump unit is typical between 5,000 and 8,000 hour. Pump unit can be exchanged at our facility.

Price, availability and p/n – look under Commerce
